ASTM A240 Stainless Steel 316 Sheet
ASME SA 240 Type 316 Plate supplier in Mumbai
ASTM A240 Stainless Steel 316 Sheet
316 Stainless Steel Plate
316L Stainless Steel Coil
AISI 316 AMS 5524, 316 Stainless Steel Strip, Perforated 316 stainless steel sheet manufacturers in India
ASTM A240 Type 316 is the second-most common stainless steel next to 304. Stainless Steel Sheet Type 316 generally contains 16% chromium and 10% nickel, with the addition of molybdenum normally ranging from 2-3%. Molybdenum increases corrosion resistance, particularly against chlorides and other industrial solvents. While there may be a difference between the chemical compositions of SA 240 type 316L Perforated Sheet and 304, their mechanical properties are similar.
ASTM A240 Grade 316 Chequered Plate is commonly used in many industrial applications involving processing chemicals, as well as high-saline environments such as coastal regions and outdoor areas where de-icing salts are common. Due to its non-reactive qualities, 316 Stainless Steel Strip & Mesh Sheet is also used in the manufacture of medical surgical instruments. 316 Stainless Steel is more corrosion resistant than grade 304 and is suitable for marine and coastal applications.
Nirmaan Steel stocks 316-2B Stainless Steel Sheet, ASTM A240 Type 316 Expanded Sheet, 316 Etching Plate, 316 Embossing sheet, SS 316 Hairline Plate, 316 Diamond Sheet, Bright Annealed 316 Plate is an austenitic chrome nickel steel with superior corrosion resistance to that of other chrome nickel steels. Widely used when exposed to chemical corrodents, as well as marine atmospheres. 316-2B is a bright cold rolled mill finish. The end result of the cold rolling process creates a reflective finish that can be further polished.
Looking for best price of Stainless Steel 316 Corrugated Sheet in India? We have no minimum footage requirements. We will supply the exact amount of No 8 Mirror Finish 316 Stainless Steel Plate you require even if it’s small quantity of 316 Stainless Steel Laminate Sheet. Contact Nirmaan Steel- the right supplier of Stainless Steel 316 Design Sheet near you.
Nirmaan Steel offers one of the widest ranges of SS 316 sheet and plate in various qualities, sizes and grades which are equivalent to Stainless Steel 316 Plate (2mm to 12mm). SS 316 Sheet is available in thicknesses ranging from .016 to .156″. Large size SS UNS S31600 Plate will also diminish the size of the undesirable heat-affected zone caused by welding. We also stock & supply No 8 Mirror Finish Stainless Steel 316 Sheet, extra large-size Sheets, thin and ultra-thin gauge strip and foil products, rolled down to 2 microns.
Superior technology as well as extensive quality control from steelmaking to finishing assure the stable production of Stainless Steel 316 Hot Rolled Plate in uniformly of excellent quality. We apply the process of surface finishing to our AISI 316 Polished Plate by pickling or buff-polishing. SUS 316L Strips levels of finishing & cut can be adjusted according to your requirements. SS 316 Plate is available in the form of Sheet, Coils, Foils, Rolls, Plain Plate, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Stainless Steel 316 Plate Weight Calculator allows you to calculate an estimate of the weight of different sizes of Stainless Steel 316 Plate & Bright Annealed ASTM A240 Stainless Steel 316L Plate based on dimensions and shape. SS Werkstoff No 1.4401 Shim is sold in either 300mm or 600mm rolls and sheet form. The thin material can be used in power plants, nuclear plants or gas and oil refineries.
Our 316 Stainless Steel Diamond Sheet has as near a perfect polish that can be produced on stainless steel. 316 Perforated stainless steel sheets can be used for technical purposes such as strainers, filters and sieves in food processing, brewing and acoustic diffusers as well as interior design and architectural features. The finish referred to as “Brushed Finish” has a trade reference “DP” which means “Dull Polish”. This finish is achieved using grit in the polishing media. Variations in the brush effect are obtained by using grits of different sizes. Stainless Steel 316L Cold Rolled Plate finishes include Natural, Bright, Brushed, Dull Polished, Mirror and Embossed Rigidised.
Our Dealers & Distributors in UK, USA, Indonesia, Israel, Germany, Canada, UAE, Saudi Arabia, Malaysia, Singapore, Russia, France, Italy,Oman, Kuwait, Qatar, Sweden, Iran & Australia arrange complete range of 316 Stainless Steel Decorative Sheet, 316 SS Embossed Sheet, SS GOST 03Ch17N14M3 Plate, ASME SA240 Stainless Steel 316 Foil Sheet, SS Grade 316 Hairline Sheet, SS UNS S31600 Laminate Sheet and AISI 316 Plate in shortest time as well at best price, because we maintain Stainless Steel 316 Plate in stock for sale, so it saves time & cost to procure any size range in Bright annealed Stainless Steel 316 Plate from any other vendor or Manufacturer of mirror finish Stainless Steel 316 Sheet in India. Click here to check recent Jindal stainless steel sheet price list.
Table of contents
- ASTM A240 Grade 316 Sheet Price
- 316 Stainless Steel Plate Specification
- Stainless Steel 316 Sheet Thickness
- Embossed & Rigidised Stainless Steel 316 Sheet
- Perforated Stainless Steel Sheet 316
- Plain & Polished 316 Stainless Steel Sheet
- Super Mirror Stainless Steel Sheet 316
- 316/316L Stainless Steel Sheet Sizes
- SA 240 type 316L Sheet Weight Chart
- Stainless Steel 316 Sheet Dimensions
- ASTM A240 Type 316 Sheet Properties
- Difference Between Inconel and Stainless Steel
Looking to buy 304 Stainless Steel Plate? 304 Stainless Steel Sheet?
ASTM A240 GRADE 316 SHEET PRICE
Stainless Steel 316 Sheet Price List
| Thickness | Price in Euro £ |
|---|---|
| 2000mm x 1000mm 316 Stainless Steel Sheet | |
| 0.9mm | 102.46 |
| 1.2mm | 146.96 |
| 1.5mm | 178.11 |
| 2.0mm | 230.71 |
| 3.0mm | 270.79 |
Finish: Dull Polished/ Mill
Please note: Price is subject to change without any prior notice.
STAINLESS STEEL 316 PLATE SPECIFICATION
AMS 5524 Sheet / strip / plate (316)
AMS 5507 Sheet / strip/ plate (316L)
| Stainless Steel 316 Plate ASTM Specification | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
| SS 316 Plate Specification | MSRR, AMS, BS, ASTM A240 / ASME SA240 |
| Stainless Steel 316 Plate Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 m x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36″ X 120″ or 48″ X 144″, 4′ x 8′, Cut to size available |
| Stainless Steel 316 Plate Thickness | 0.1mm to 100 mm Thk |
| Stainless Steel 316 Plate Width | 10-2500mm |
| Stainless Steel 316 Plate AMS | AMS 5524 |
| Stainless Steel 316 Plate Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper Condition | Annealed |
| Stainless Steel 316 Plate Finish | Polished on both sides |
| Stainless Steel 316 Sheet Stock in form of | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Stainless Steel 316 Sheet ASTM Standard | SS 316 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| Value Added Service | ASTM A162, GB/T2054, DIN177502002, ASTM B127, ASTM B435, ASTM B582, ASTM B575, ASTM B168, ASTM B443, ASTM B463, ASTM B626, ASTM B536, etc |
| Dealers & Distributor of | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| High Quality Stainless Steel 316 Sheet | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material • Huge Stock, Timely delivery • Raw Materials Certificate • EN 10204/3.1B • 100% Radiography Test Report • High special strength, high melt point • Third Party Inspection Report, etc • Excellent corrosive resistance, good thermal resistance • Customer support after-sales service • Strict Control from Raw Material to Finished Stainless Steel 316 Sheet |
| Stainless Steel 316 profiling | To provide a full profiling service we use numerous profiling methods including: • Plasma Plate Cutting • Laser Plate Cutting • Oxy-propane Flame Cutting |
| Specialized in | • Stainless Steel 316 Sheet: material under 3/16″ [5.00 mm] in thickness and 24″ [600 mm] and over in width • Stainless Steel 316 Plate: material 3/16″ [5.00 mm] and over in thickness and over 10″ [250 mm] in width • Stainless Steel 316 Strip: cold-rolled material under 3/16″ [5.00 mm] in thickness and under 24″ [600 mm] in width • Stainless Steel 316 Clad plate: Stainless Steel 316 Clad plate is a composite steel plate made by bonding Stainless Steel 316 plate, etc. • Free Quote, Inquiry answered within 24 hours |
Nirmaan Steel offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing.
ASTM A240 316l Stainless Steel Plate Specifications
ASTM A240 316L stainless steel plate specifications are that it has a Density of 0.285 lbs/in3 (7.90 g/cm3). The Ultimate Tensile Strength of ASTM A240 316L stainless steel is 80900 psi (558 MPa). The Yield Tensile Strength of ASTM A240 316L stainless steel is 42100 psi (290 MPa). The Specific Heat of ASTM A240 316L stainless steel is 450 J/kg-°K (0–100°C) [0.11 BTU/lb-°F (32–212°F)]. ASTM A240 316L stainless steel has a Rockwell B Hardness of 79. The Modulus of Elasticity of ASTM A240 316L stainless steel Plate is 200 GPa (29.0 x 106 psi). ASTM A240 316L stainless steel has an Elongation at Break of 50%.Types of Stainless Steel 316 Sheet
AMS 5524 2B Sheet
Decorative 8K Mirror AMS 5507 Stainless Steel Sheet
Hairline ASTM A240 UNS S31600 Sheet
No.4 ASTM A240 UNS S31603 Sheet
SA 240 type 316 Plate
SA 240 type 316L Sheet
ASTM A240 Grade 316 Coil
ASTM A240 Grade 316L Clad Plate
ASTM A240 Type 316 Strips
ASTM A240 Type 316L Shim Stock
SS UNS S31600 Rolling Sheets
AISI 316 Flat Sheet
ASTM A240 Stainless Steel 316L Rolling Plate
Stainless Steel 316 Flat Shim
Stainless Steel 316 Perforated Plate
Stainless Steel 316 Polished Plate
Stainless Steel 316 cold rolled sheet
Stainless Steel 316 hot rolled plate
SS 316 Plate
SS 316 Sheet
Stainless Steel 316 Quarto Plate
Stainless Steel 316 Precision Strip
SS 316 Cold Rolled Coil, Strip And Sheet
SS 316 Hot Rolled Coil, Strip And Plate
TYPES OF STAINLESS STEEL 316 SHEET, PLATE & FOIL
| ASTM A240 Type 316 Shim Sheet | 316 Stainless Steel Perforated Sheet |
| SA240 316 Stainless Steel Chequered Plate | 316 Stainless Steel Strip |
| SS Werkstoff No 1.4301 Shims | Brushed 316 Stainless Steel Plate |
| Polished 316 Stainless Steel Plate | 316 Stainless Steel Coil Slitting |
| 316 Stainless Steel Patterned Sheet | Decorative 316 Stainless Steel Sheet |
| Zinc Coated 316 Stainless Steel Plate | Jindal 316 Stainless Steel Plate |
| 316 Stainless Steel Bbq Plate | ASTM A240 Type 316 gold mirror etching |
| Cold Rolled 316 Stainless Steel Plate | SA 240 type 316 Pattern Elevator Door sheet |
| Mirror Etching Elevator Door Sheet | SS Grade 316 Etching Sheet |
| SA240 Color sheet | ASTM A240 Type 316 Embossing sheet |
| SS UNS S31600 Stamped sheet | ASTM A240 Grade 316 Polish Plate |
| ASTM A240 Type 316 Laminate Sheet | 316 Stainless Steel Floor Sheet |
| Brushed Finish grade 316 Stainless Steel Plate | Smooth Finish AISI 316 Plate |
| Circle Polished grade 316 Stainless Steel Sheet | ASTM A240 Type 316 Mesh Sheet |
| Bright Annealed ASTM A240 Type 316 Plate | 316 Stainless Steel Corrugated Sheet |
| 316 Stainless Steel Diamond Sheet | A240 Grade 316 Thick Steel Plate |
| SUS 316 Design Sheet | 316 Stainless Steel Expanded Sheet |
| Embossed 316 Stainless Steel Sheet | ASTM A240 Grade 316 Checker Plate |
| ASTM A240 Type 316 Foil Sheet | SS Werkstoff No 1.4401 Flat Strip |
| 316 Stainless Steel Cold Rolled Plate | No 8 Mirror Finish 316 Stainless Steel Plate |
Difference between Stainless Steel 316 Sheet, Plate & Foil
Here are few points to recognised sheet, plate or foil:
If thickness greater than 6.35 mm is called a Stainless Steel 316 Plate.
If thickness greater than 0.15 mm and less than 6.35mm is called a Stainless Steel 316 Sheet.
If thickness less than 0.15mm is then its a Stainless Steel 316 Foil.
Embossed Stainless Steel 316 Sheet
316 Perforated Stainless Steel Sheet
316 Super Mirror Stainless Steel Sheet
TYPES OF STAINLESS STEEL 316 SHEET, PLATE & FOIL
| ASTM A240 Type 316 Shim Sheet | 316 Stainless Steel Perforated Sheet |
| SA240 316 Stainless Steel Chequered Plate | 316 Stainless Steel Strip |
| SS Werkstoff No 1.4301 Shims | Brushed 316 Stainless Steel Plate |
| Polished 316 Stainless Steel Plate | 316 Stainless Steel Coil Slitting |
| 316 Stainless Steel Patterned Sheet | Decorative 316 Stainless Steel Sheet |
| Zinc Coated 316 Stainless Steel Plate | Jindal 316 Stainless Steel Plate |
| 316 Stainless Steel Bbq Plate | ASTM A240 Type 316 gold mirror etching |
| Cold Rolled 316 Stainless Steel Plate | SA 240 type 316 Pattern Elevator Door sheet |
| Mirror Etching Elevator Door Sheet | SS Grade 316 Etching Sheet |
| SA240 Color sheet | ASTM A240 Type 316 Embossing sheet |
| SS UNS S31600 Stamped sheet | ASTM A240 Grade 316 Polish Plate |
| ASTM A240 Type 316 Laminate Sheet | 316 Stainless Steel Floor Sheet |
| Brushed Finish grade 316 Stainless Steel Plate | Smooth Finish AISI 316 Plate |
| Circle Polished grade 316 Stainless Steel Sheet | ASTM A240 Type 316 Mesh Sheet |
| Bright Annealed ASTM A240 Type 316 Plate | 316 Stainless Steel Corrugated Sheet |
| 316 Stainless Steel Diamond Sheet | A240 Grade 316 Thick Steel Plate |
| SUS 316 Design Sheet | 316 Stainless Steel Expanded Sheet |
| Embossed 316 Stainless Steel Sheet | ASTM A240 Grade 316 Checker Plate |
| ASTM A240 Type 316 Foil Sheet | SS Werkstoff No 1.4401 Flat Strip |
| 316 Stainless Steel Cold Rolled Plate | No 8 Mirror Finish 316 Stainless Steel Plate |
316 PERFORATED STAINLESS STEEL SHEET
We now offer circle cutting in ss 316 perforated sheets up to 1000mm diameter.
| Hole Dia (in mm) | Hole Centres (in mm) | O/A | Finish | Tck mm | Full Sheet Size mm |
|---|---|---|---|---|---|
| 0.75 | 1.5 | 23% | 2B | 0.6 | 2000 x 1000 |
| 1 | 2 | 23% | 2B | 1.0 | 2000 x 1000 |
| 1.5 | 2.6 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 3 | 5 | 33% | 2B | 1.0 | 2000 x 1000 |
| 4 | 5.6 | 46% | 2B | 1.0 | 2000 x 1000 |
| 5 | 8 | 35% | 2B | 1.0 | 2000 x 1000 |
| 6 | 8 | 51% | 2B | 1.0 | 2000 x 1000 |
| 8 | 10 | 58% | 2B | 1,0 | 2000 x 1000 |
PLAIN AND POLISHED 316 STAINLESS STEEL SHEETS
Nirmaan Steel are suppliers of a range of polished stainless steel 316 sheets, finishes include Natural, Bright, Brushed, Dull Polished, Mirror and Embossed Rigidised
| PRODUCT | FINISH | THICKNESS MM | MAX SHEET SIZE MM |
|---|---|---|---|
| Grade 316 | Plain 2B | 0.9 | 2000 x 1000 |
| Grade 316 | Bright | 0.9 | 2000 x 1000 |
| Grade 316 | Brushed Finish | 0.9, 1.2 | 2000 x 1000, 2500 x 1250 |
| Grade 316 | Rimex Super Mirror | 0.8, 1.2 | 2400 x 1200, 2500 x 1250 |
| Grade 316 | Embossed | 0.8, 1.0 | 2500 x 1250 |
316 SUPER MIRROR STAINLESS STEEL PLATE
316 Stainless Steel Checker Plate suppliers and exporter in India
Nirmaan Steel are suppliers and fabricators of 316 Mirror Stainless Steel Sheet Metal. Our Mirror stainless steel 316 sheet has as near a perfect polish that can be produced on stainless steel. Super Mirror is blemish free, it has no grain and has reflective qualities just like a glass mirror. It can be fabricated with conventional sheet metal machinery. Folded, rolled, engraved.
Stainless Steel 316 Sheet Weight
The Poissons Ratio of stainless steel 316 is 0.25. Stainless steel 316 has a Shear Modulus of 77.0 GPa (11200 ksi). The Electrical Resistivity of stainless steel 316 is 0.0000740 ohm-cm. The stainless steel 316 sheet weight can easily be got by using an online calculator. The Magnetic Permeability of stainless steel 316 is <= 1.02. Stainless steel 316 has a Solidus of 2500 °F (1371 °C). The Liquidus of stainless steel 316 is 2550 °F (1399 °C). Click on below tab to view the weight chart.
| Size | Size |
|---|---|
| .125" | 3.18mm |
| .134" | 3.40mm |
| .156" | 3.96mm |
| .187" | 4.75mm |
| .250" | 6.35mm |
| .312" | 7.92mm |
| .375" | 9.53mm |
| .500" | 12.7mm |
| .625" | 15.9mm |
| .750" | 19.1mm |
| .875" | 22.2mm |
| 1" | 25.4mm |
| 1.125" | 28.6mm |
| 1.250" | 31.8mm |
| 1.500" | 38.1mm |
| 1.750" | 44.5mm |
| 2" | 50.8mm |
| 2.500" | 63.5mm |
| 3" | 76.2mm |
Stainless Steel 316 Sheet Weight & Density, Stainless Steel 316 Plate Weight per Unit
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 Inches | 0.06000 lbs/in² 42.184176 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 1/4 Inches | 0.08 lbs/in² 56.245568 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 3/8 Inches | 0.121 lbs/in² 85.0714216 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 1/2 Inches | 0.161 lbs/in² 113.1942056 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 5/8 Inches | 0.196 lbs/in² 137.8016416 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 3/4 Inches | 0.235 lbs/in² 165.221356 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 7/8 Inches | 0.274 lbs/in² 192.6410704 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 1 Inches | 0.313 lbs/in² 220.0607848 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 1 1/4 Inches | 0.391 lbs/in² 274.9002136 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 1 1/2 Inches | 0.47 lbs/in² 330.442712 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 1 3/4 Inches | 0.549 lbs/in² 385.9852104 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 2 Inches | 0.627 lbs/in² 440.8246392 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 2 1/4 Inches | 0.705 lbs/in² 495.664068 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 2 1/2 Inches | 0.784 lbs/in² 551.2065664 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 2 3/4 Inches | 0.862 lbs/in² 606.0459952 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
| 3 Inches | 0.941 lbs/in² 661.5884936 kg/m² | 0.315 lbs/in³ 8.72 g/cm³ |
Stainless Steel 316 Plate Metric Dimensions
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B - Cold rolled, heat treated, pickled, skin passed | 0.25-8.0 | max. 2032 |
| 2D - Cold rolled, heat treated, pickled | 0.4-6.35 | max. 1524 |
| 2E - Cold rolled, heat treated, mechanically descaled | 0.4-8.0 | max. 2032 |
| 2R - Cold rolled, bright annealed | 0.25-3.5 | max. 1524 |
| 2H - Work hardened | 0.4-6.35 | max. 1524 |
| Polished, brushed | 0.5-4.0 | max. 1524 |
Stainless Steel 316 Plate Imperial Dimensions
| Surface finish | Gauge (in) | Width (in) |
|---|---|---|
| 2B - Cold rolled, heat treated, pickled, skin passed | 10-24 | max. 72* |
| 2D - Cold rolled, heat treated, pickled | 12-24 | max. 60 |
| BA Mexinox only | 18-28 | max. 48 |
| Polished (not brushed) | 11-24 | max. 60 |
| Temper rolled Mexinox only | 13-29 | max. 48 |
ASTM A240 Type 316 Sheet Properties
SS 316 Plates, ASTM A240 Grade 316 & 316L Stainless Steel Sheet suppliers
ASTM A240 type 316 Plate properties are that it has a Chemical Composition of Nitrogen 0.1, Nickel 10.0 min. – 14.0 max., Chromium 16.0 min. – 18.0 max., Manganese 2.00, Silicon 0.75, Molybdenum 2.00 min.– 3.00 max., Phosphorous 0.045, Carbon 0.08, Sulfur 0.03 and Iron balance. At 100 °C (212 °F) ASTM A240 type 316 has a Thermal Conductivity of 14.6 W/m-°K (10.1 BTU/hr/ft2/ft/°F). ASTM A240 type 316 has a Melting Range of 1390–1440 °C (2450–2630 °F). The Electrical Resistivity of ASTM A240 type 316 is 29.1 Microhm-in at 68 °F (74 Microhm-cm at 20 °C). ASTM A240 type 316 has a Tensile Modulus of 28000 ksi (193 GPa).
SS 316 Plate, Sheet & Coil Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| SS 316 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
Stainless Steel 316 Sheets, Plates & Coils Mechanical Properties
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2% Offset) | Elongation |
|---|---|---|---|---|---|
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Equivalent Grades for 316 Stainless Steel Sheets & Plate
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17-11-02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Special Steel
- Carbon Steel Pipe
- ASTM A106 Grade B Pipe
- ASTM A53 Grade B Pipe
- ASTM A333 Grade 6 Pipe
- IS 4923 Steel Pipes
- ASTM A179 Pipe
- ASTM A192 Tube
- BS 3059 Boiler Tube
- SA 210 Boiler Tube
- DIN 2391 ST 52
- ASTM A671 Pipe
- ASTM A671 Grade CC60
- ASTM A671 Grade CC65
- ASTM A671 Grade CC70
- ASTM A672 Pipe
- ASTM A672 Grade C55
- ASTM A672 Grade C60
- ASTM A672 Grade C65
- ASTM A672 Grade C70
