Hastelloy C22 Sheet

Hastelloy C22 Sheet suppliers

Alloy C22 Plate, 2.4602 Grade Plate suppliers in India

Buy Hastelloy C22 Plate, Alloy C22 UNS N06022 Plate, 2.4602 Material Sheet at best price in Mumbai, India

Hastelloy C22 Plate

Hastelloy C22 Coil

The room temperature hardnesses of Hastelloy C22 sheet and Alloy C22 Plate are approximately 93 HRB and 95 HRB, respectively. The values are averages from numerous tests. Hastelloy C22 plate is very amenable to the Gas Metal Arc (GMA/MIG), Gas Tungsten Arc (GTA/TIG), and Shielded Metal Arc (SMA/Stick) welding processes. Alloy C22 Din 2.4602 Coil, Alloy C22 UNS N06022 Clad Plate & ASTM B575 UNS N06022 Shim are supplied in the Mill Annealed (MA) condition, unless otherwise specified. The specification of Hastelloy Sheet, Plate & Strip is ASTM / ASME SB 575/B 575 P= 43. 2.4602 Material Sheet is designated as UNS N06022 and Werkstoff Number 2.4602. 2.4602 Grade Perforated Plate, 2.4602 Alloy 22 Cold rolled Plate, Foil &Rolling Sheets can be cold formed by standards methods.

Looking for best price of Hastelloy C22 Strip in India? We have no minimum footage requirements. We will supply the exact amount of Hastelloy Alloy C22 Plate you require even if it’s small quantity of Hastelloy C22 Rolling Plate. Contact Nirmaan Steel – the right supplier of Hastelloy C22 Flat Shim near you.

Nirmaan Steel offers one of the widest ranges of Alloy C22 sheet and Alloy C22 plate in various qualities, sizes and grades which are equivalent to Hastelloy C22 Sheet & Hastelloy C22 Plate (2mm to 12mm). Hastelloy C22 Sheet is available in thicknesses ranging from .016 to .156″. Large size Hastelloy C22 plate will also diminish the size of the undesirable heat-affected zone caused by welding. We also stock & supply extra large-size Hastelloy C22 Sheets, thin and ultra-thin gauge Hastelloy Alloy C22 strip and foil products, rolled down to 2 microns.

Superior technology as well as extensive quality control from steelmaking to finishing assure the stable production of Hastelloy C22 Hot Rolled Plates in uniformly of excellent quality. We apply the process of surface finishing to our Hastelloy C22 Polished Plate by pickling or buff-polishing. Hastelloy C22 Strips levels of finishing & cut can be adjusted according to your requirements. Hastelloy C22 Plate is available in the form of Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Hastelloy C22 Plate Weight Calculator allows you to calculate an estimate of the weight of different sizes of Hastelloy C22 plates based on dimensions and shape.

Our Dealers & Distributors in India arrange complete range of Hastelloy C22 plates in shortest time as well at best price, because we maintain Hastelloy C22 Sheet in stock for sale, so it saves time & cost to procure any size range in Bright annealed Hastelloy C22 sheet from any other vendor or Manufacturer of mirror finish Hastelloy C22 plate in India.

Do you Know?

The largest fabrication of HASTELLOY® C-22® alloy known to-date is shown here being thin sheet lined for exposure in a utility flue-gas desulfurization plant. Hastelloy C22 sheet is still providing excellent service after 10 years. (Ref: Haynes)

Distributor of 2.4602 Alloy 22 Plate in Mumbai, India

Looking to buy Inconel Plate ? Inconel Sheet ?

Check price of Inconel Plate in India

Hastelloy C22 Plate Price

Hastelloy C22 Sheet Price List

Material Sheet Price	Origin	Price in INR (per kg)	Price in USD (per kg)	Price in Euro (per kg)	Others
Alloy C22 Din 2.4602 Sheets Price in India	Indian	Rs 2700 – 2800/- (As per dependent your size)	$39	€33	Cut to Size
Alloy C22 Plate Price in Japan	Japanese	Rs 3500 – 3600/- (As per dependent your size)	$52	€44	Fix Length
Alloy C22 UNS N06022 Plate Price in UK / Europe	European	Rs 4000 – 4100/- (As per dependent your size)	$59	€50	Fix Length
ASTM B575 UNS N06022 Plate Price in USA	USA	Rs 4500 – 4600/- (As per dependent your size)	$66	€57	Fix Length

Please note: Price is subject to change without any prior notice.

Alloy C22 Plate Price Per KG

Alloy C22 plate price per kg is Rs. 2700 in India. As such, in Great Britain, the cost per kilo of 2.4602 Grade Plate would be around 29.50 Pounds. This would not mean that Alloy C22 plates would be available at the same price in different parts of the globe such as China, USA, Singapore, Japan, Europe, etc. Also, the cost of Alloy C22 plates, keeps changing from time to time. Fact is, you could probably get Alloy C22 plates in India, at 35% lesser than they could be got in the USA. Or, Alloy C22 plates could be bought in Japan, for 20% more than they could be got in India.

Click here to check complete (grade & size wise)

HASTELLOY C22 PLATE SPECIFICATION

Hastelloy C22 Sheet ASTM Specification	ASTM B575
Hastelloy C22 Plate, Sheet and Strip Specification	ASTM B 575; ASTM B 906 & ASME SB 575; ASME SB 906, ASME Code Case 2226, ASME Code Case N-621, ISO 6208, DIN 17750
Alloy C22 Plate Specification	MSRR, AMS, BS, ASTM B575 / ASME SB575
Length & Sizes	1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36″ X 120″ or 48″ X 144″, Cut to size available
Thickness	0.1mm to 100 mm Thk
Width	10-2500mm
AMS	AMS
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Temper	Annealed
Condition	Polished on both sides
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Stock in form of	Alloy C22 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate
High Quality	Huge Stock, Timely delivery Raw Materials Certificate EN 10204/3.1B 100% Radiography Test Report High special strength, high melt point Third Party Inspection Report, etc Excellent corrosive resistance, good thermal resistance Customer support after-sales service Strict Control from Raw Material to Finished Hastelloy C22 plate
Hastelloy C22 profiling	To provide a full profiling service we use numerous profiling methods including: Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting
Specialized in	Hastelloy C22 Sheet: material under 3/16″ [5.00 mm] in thickness and 24″ [600 mm] and over in width Hastelloy C22 Plate: material 3/16″ [5.00 mm] and over in thickness and over 10″ [250 mm] in width Hastelloy C22 Strip: cold-rolled material under 3/16″ [5.00 mm] in thickness and under 24″ [600 mm] in width Hastelloy C22 Clad plate: Hastelloy C22 Clad plate is a composite steel plate made by bonding Hastelloy C22 plate, etc. Free Quote, Inquiry answered within 24 hours

Nirmaan Steel offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing.

Types of Hastelloy C22 Plate

Hastelloy C22 2B Sheet

Decorative 8K Mirror Hastelloy C22 Sheet

Hairline Hastelloy C22 Sheet

No.4 Hastelloy C22 Sheet

Hastelloy C22 Plate

Hastelloy C22 Sheet

Hastelloy C22 Coil

Hastelloy C22 Clad Plate

Hastelloy C22 Strips

Hastelloy C22 Shim Stock

Hastelloy C22 Rolling Sheets

Hastelloy C22 Flat Sheet

Hastelloy C22 Rolling Plate

Hastelloy C22 Flat Shim

Hastelloy C22 Perforated Plate

Hastelloy C22 Polished Plate

Hastelloy C22 cold rolled sheet

Hastelloy C22 hot rolled plate

Alloy C22 Plate

Alloy C22 Sheet

Hastelloy C22 Quarto Plate

Hastelloy C22 Precision Strip

Alloy C22 Cold Rolled Coil, Strip And Sheet

Alloy C22 Hot Rolled Coil, Strip And Plate

Difference between Hastelloy C22 Sheet, Plate & Foil

Here are few points to recognised sheet, plate or foil:

If thickness greater than 6.35 mm is called a Hastelloy C22 Plate.

If thickness greater than 0.15 mm and less than 6.35mm is called aHastelloy C22 Sheet.

If thickness less than 0.15mm is then its a Hastelloy C22 Foil..

Hastelloy C22 Plate Properties

Hastelloy C22 Plate mechanical properties

Hastelloy C22 Plate, Sheet & Coil Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max

Alloy C22 Sheets, Plates & Coils Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %

Hastelloy C22 Sheet Equivalent & Uses

Hastelloy C22 sheet equivalent & uses is that Hastelloy C22 equivalent is UNS N06022. Hastelloy C22 sheets are used in a number of applications and industries and some of these are Electro-Galvanizing Rolls, Pesticide Production, Acid Etching, Plate Heat Exchangers, Sulfonation Systems, HF Furnace Scrubbers, Chlorination Systems, Tubular Heat Exchangers, Flue Gas Scrubber Systems, Actic Acid/Acetic Anhydride, etc. The Density of Hastelloy C22 is 0.314 lb/in³ (8.69 g/cm³). The Melting Point of Hastelloy C22 is 2550 °F (1399 °C). Hastelloy C22 Elastic Modulus is 29878 psi (206 MPa).

Equivalent Grades for C22 Hastelloy Sheets & Plates

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–

Hastelloy C22 Sheet Sizes

Sizes in Inches	Sizes in mm
.125″	3.18mm
.134″	3.40mm
.156″	3.96mm
.187″	4.75mm
.250″	6.35mm
.312″	7.92mm
.375″	9.53mm
.500″	12.7mm
.625″	15.9mm
.750″	19.1mm
.875″	22.2mm
1″	25.4mm
1.125″	28.6mm
1.250″	31.8mm
1.500″	38.1mm
1.750″	44.5mm
2″	50.8mm
2.500″	63.5mm
3″	76.2mm

Metric Dimensions

Surface finish	Thickness (mm)	Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed	0.25–8.0	max. 2032
2D – Cold rolled, heat treated, pickled	0.4–6.35	max. 1524
2E – Cold rolled, heat treated, mechanically descaled	0.4–8.0	max. 2032
2R – Cold rolled, bright annealed	0.25–3.5	max. 1524
2H – Work hardened	0.4–6.35	max. 1524
Polished, brushed	0.5–4.0	max. 1524

Imperial Dimensions

Surface finish	Gauge (in)	Width (in)
2B – Cold rolled, heat treated, pickled, skin passed	10–24	max. 72*
2D – Cold rolled, heat treated, pickled	12–24	max. 60
BA Mexinox only	18–28	max. 48
Polished (not brushed)	11–24	max. 60
Temper rolled Mexinox only	13–29	max. 48

An estimated delivery time location wise for Hastelloy C22 Sheet & Plate

Country	Days	Country	Days
USA	45	Canada	45
Australia	30	UK	35
Malaysia	15	Poland	15
Iran	7	Singapore	14
Vietnam	20	Albania	20
UAE	15	Thailand	20
Nigeria	40	Ethiopia	40
Turkey	30	Tanzania	30
Bahrain	15	Kenya	40
Libya	40	Syria	40
Zambia	40	Egypt	40
Italy	40	India	7
Saudi Arabia	15	Qatar	15
Namibia	40	Indonesia	20
South Africa	40	Australia	40
Uganda	40	Angola	40
Kazakhstan	20	Algeria	20

Suppliers of Hastelloy B2 Sheet in UK, Singapore & Nirmaan Steel
