Incoloy 825 plate suppliers
Alloy 825 Sheet, UNS N08825 plate suppliers in India
Buy Incoloy 825 Sheet, astm b424 uns n08825, Incoloy Alloy 825 strip in Mumbai
Incoloy 825 Plate
Incoloy 825 Sheet
Incoloy 825 Coil
Incoloy 825 Plate is a nickel-iron-chromium alloy with additions of molybdenum, copper and titanium. Alloy 825 Plate has excellent resistance to both reducing and oxidizing acids, to stress-corrosion cracking, and to localized attack such as pitting and crevice corrosion. Incoloy 825 Coil is designated as UNS N08825 and Werkstoff Number 2.4858. Incoloy Alloy 825 Plate also known as Incoloy 825 Clad Plate, Inconel 825 Plate & Nickel Alloy 825 Plate. Incoloy 825 Flat Shim, Incoloy 825 Perforated Plate, Incoloy 825 Cold rolled Plate, Incoloy 825 Foil & Incoloy 825 Rolling Sheets can be cold formed by standards methods.
Looking for best price of Incoloy 825 Shim in India? We have no minimum footage requirements. We will supply the exact amount of Incoloy 825 Strip you require even if it’s small quantity of Incoloy 825 Flat Sheet. Contact Nirmaan Steel– the right supplier of Incoloy 825 Rolling Plate near you.
Nirmaan Steel offers one of the widest ranges of Alloy 825 sheet and Alloy 825 plate in various qualities, sizes and grades which are equivalent to Incoloy 825 Sheet & Incoloy 825 Plate (2mm to 12mm). Incoloy 825 Sheet is available in thicknesses ranging from .016 to .156″. Large size Incoloy 825 plate will also diminish the size of the undesirable heat-affected zone caused by welding. We also stock & supply extra large-size Incoloy 825 Sheets, thin and ultra-thin gauge Incoloy Alloy 825 strip and foil products, rolled down to 2 microns.
Superior technology as well as extensive quality control from steelmaking to finishing assure the stable production of Incoloy 825 Hot Rolled Plates in uniformly of excellent quality. We apply the process of surface finishing to our Incoloy 825 Polished Plate by pickling or buff-polishing. Incoloy 825 Strips levels of finishing & cut can be adjusted according to your requirements. Incoloy 825 Plate (UNS N08825 plate) is available in the form of Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Incoloy 825 Plate Weight Calculator allows you to calculate an estimate of the weight of different sizes of Incoloy 825 plates based on dimensions and shape.
Our Dealers & Distributors in India arrange complete range of Incoloy 825 plates in shortest time as well at best price, because we maintain Incoloy 825 Sheet in stock for sale, so it saves time & cost to procure any size range in Bright annealed Incoloy 825 sheet from any other vendor or Manufacturer of mirror finish Incoloy 825 plate in India.
Distributor of Incoloy 825 Clad Plate, Incoloy 825 Sheet, AMS 5542 Incoloy UNS N08825 Shim exporter in India
Table of contents
- Incoloy 825 Plate Price
- Incoloy 825 plate Suppliers
- Alloy 825 plate Specification
- Incoloy 825 Sheet Properties
- Incoloy 825 Plate Sizes
- Difference Between Inconel and Incoloy
Looking to buy Inconel 625 Plate ? Inconel 625 Sheet ?
Check price of Inconel 625 Plate in India
Incoloy 825 Plate Price
Incoloy 825 Sheet Price List
| Incoloy 825 Sheet Price | Origin | Price in INR (per kg) | Price in USD (per kg) | Price in Euro (per kg) | Others |
|---|---|---|---|---|---|
| Incoloy 825 Sheet Price in India | Indian | Rs 1400 – 1500/- | $20 | €17 | Cut to Size |
| Incoloy 825 Sheet Price in Japan | Japanese | Rs 1650 – 1750/- | $25 | €21 | Fix Length |
| Incoloy 825 Sheet Price in UK / Europe | European | Rs 1760 – 1860/- | $26 | €22 | Fix Length |
| Incoloy 825 Sheet Price in USA | USA | Rs 1800 – 1900/- | $27 | €23 | Fix Length |
Please note: Price is subject to change without any prior notice.
INCOLOY 825 PLATE SPECIFICATION
Nickel Alloy 825 and Incoloy® 825 Plate, Sheet and Strip Standards
BS 3072NA16 BS 3073NA16 ASTM B 424 ASTM B 906 ASME SB 424 ASME SB 906 DIN 17750 VdTÜV 432 ISO 6208| Incoloy 825 Sheet ASTM Specification | ASTM B424 UNS N08825, ASME SB424 |
|---|---|
| Alloy 825 Plate Specification | MSRR, AMS, BS, ASTM B424 / ASME SB424 |
| Incoloy 825 Plate Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36″ X 120″ or 48″ X 144″, Cut to size available |
| Incoloy 825 Plate Thickness | 0.1mm to 100 mm Thk |
| Incoloy 825 Plate Width | 10-2500mm |
| Incoloy 825 Sheet AMS | AMS 5542 |
| Incoloy 825 Sheet Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper Condition | Annealed Polished on both sides |
| Incoloy 825 Plate Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Incoloy 825 Plate Stock in form of | Alloy 825 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| High Quality Incoloy 825 Sheet |
|
| Incoloy 825 profiling | To provide a full profiling service we use numerous profiling methods including:
|
| Specialized in |
|
Nirmaan Steel offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing.
Types of Incoloy 825 Plate
Incoloy 825 2B Sheet
Decorative 8K Mirror Incoloy 825 Sheet
Hairline Incoloy 825 Sheet
No.4 Incoloy 825 Sheet
Incoloy 825 Plate
Incoloy 825 Sheet
Incoloy 825 Coil
Incoloy 825 Clad Plate
Incoloy 825 Strips
Incoloy 825 Shim Stock
Incoloy 825 Rolling Sheets
Incoloy 825 Flat Sheet
Incoloy 825 Rolling Plate
Incoloy 825 Flat Shim
Incoloy 825 Perforated Plate
Incoloy 825 Polished Plate
Incoloy 825 cold rolled sheet
Incoloy 825 hot rolled plate
Alloy 825 Plate
Alloy 825 Sheet
Incoloy 825 Quarto Plate
Incoloy 825 Precision Strip
Alloy 825 Cold Rolled Coil, Strip And Sheet
Alloy 825 Hot Rolled Coil, Strip And Plate
AMS 5542 UNS N08825 Alloy 825 Nickel Sheet & Plate Stock List
| Alloy | Product form | Dimension (in mm) |
|---|---|---|
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard | 0.40×5 x coil, 0.016 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard rolled, special temper | 0.40×25 x coil, 0.007 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard | 0.50×5 x coil, 0.02 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, bright anneal, clean spool | 0.60×5 x spool, 0.02 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard rolled, special temper | 0.60×25 x coil, 0.011 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 0.5×914.4 x coil, 3.587 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 0.6×1219 x coil, 5.95 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed, bellows quality | 0.7×1219 x coil, 6.70 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 0.8×1220 x coil, 7.76 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 1.0×1219 x coil, 9.5 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, pickled, annealed | 1.6x1200x3000, 46.4 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, pickled, annealed | 2.0x1200x3000, 60.15 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, soft annealed, descaled, sheared | 3.0x1200x3000, 88.5 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Plate; hot rolled, soft annealed, descaled, sheared | 4.0x2440x6000, 482 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Plate; hot rolled, descaled, annealed | 5.0x2000x6000, 539 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard | 1.0×5 x coil, 0.039 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Plate; hot rolled, descaled, annealed | 18.0x260x260, 9.9 kg/pc |
STOCKED SIZES
| SIZE | ALLOY 825 | SIZE (mm) |
|---|---|---|
| .125″ | X | 3.18mm |
| .134″ | 3.40mm | |
| .156″ | X | 3.96mm |
| .187″ | X | 4.75mm |
| .250″ | X | 6.35mm |
| .312″ | X | 7.92mm |
| .375″ | X | 9.53mm |
| .500″ | X | 12.7mm |
| .625″ | X | 15.9mm |
| .750″ | X | 19.1mm |
| .875″ | 22.2mm | |
| 1″ | X | 25.4mm |
| 1.125″ | 28.6mm | |
| 1.250″ | X | 31.8mm |
| 1.500″ | X | 38.1mm |
| 1.750″ | 44.5mm | |
| 2″ | 50.8mm | |
| 2.500″ | 63.5mm | |
| 3″ | 76.2mm |
Difference between Incoloy 825 Sheet, Plate & Foil
Here are few points to recognised sheet, plate or foil:
If thickness greater than 6.35 mm is called a Incoloy 825 Plate.
If thickness greater than 0.15 mm and less than 6.35mm is called a Incoloy 825 Sheet.
If thickness less than 0.15mm is then its a Incoloy 825 Foil.
Incoloy 825 Plate Properties
Incoloy 825 Plate mechanical properties
Incoloy 825 Plate, Sheet & Coil Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
|---|---|---|---|---|---|---|---|---|---|---|
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
Alloy 825 Sheets, Plates & Coils Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Equivalent Grades for 825 Incoloy Sheets & Plates
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
|---|---|---|---|---|---|---|---|---|
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
Incoloy 825 Sheet Sizes
| Sizes in Inches | Sizes in mm |
|---|---|
| .125″ | 3.18 |
| .134″ | 3.40 |
| .156″ | 3.96 |
| .187″ | 4.75 |
| .250″ | 6.35 |
| .312″ | 7.92 |
| .375″ | 9.53 |
| .500″ | 12.7 |
| .625″ | 15.9 |
| .750″ | 19.1 |
| .875″ | 22.2 |
| 1″ | 25.4 |
| 1.125″ | 28.6 |
| 1.250″ | 31.8 |
| 1.500″ | 38.1 |
| 1.750″ | 44.5 |
| 2″ | 50.8 |
| 2.500″ | 63.5 |
| 3″ | 76.2 |
Metric Dimensions
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Imperial Dimensions
| Surface finish | Gauge (in) | Width (in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | max. 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Polished (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
An estimated delivery time location wise for Incoloy 825 Sheet & Plate
| Country | Days | Country | Days |
|---|---|---|---|
| USA | 45 | Canada | 45 |
| Australia | 30 | UK | 35 |
| Malaysia | 15 | Poland | 15 |
| Iran | 7 | Singapore | 14 |
| Vietnam | 20 | Albania | 20 |
| UAE | 15 | Thailand | 20 |
| Nigeria | 40 | Ethiopia | 40 |
| Turkey | 30 | Tanzania | 30 |
| Bahrain | 15 | Kenya | 40 |
| Libya | 40 | Syria | 40 |
| Zambia | 40 | Egypt | 40 |
| Italy | 40 | India | 7 |
| Saudi Arabia | 15 | Qatar | 15 |
| Namibia | 40 | Indonesia | 20 |
| South Africa | 40 | Australia | 40 |
| Uganda | 40 | Angola | 40 |
| Kazakhstan | 20 | Algeria | 20 |
Incoloy 825 plate in stock, Alloy 825 rolling plate suppliers
