Monel 400 Round Bar Suppliers
Alloy 400 Flat Bar, Monel 400 Rod suppliers in India
Buy Monel 400 Hex Bar, ASTM B164 Monel 400 Welding Rod, ASTM B164 Alloy 400 Bar at best Price in India & UK
Monel 400 Round Bar
Monel 400 Hex Bar
Monel 400 Square Bar
Monel 400 Round Bar / Alloy 400 Round Bar exhibits characteristics like good corrosion resistance, good weldability and high strength. The material of Monel 400 Flat Bar, Monel 400 Hexagonal Bar and Monel 400 Square Bar are designated as UNS N04400 and Werkstoff Number 2.4360. Alloy 400 Round Bar also known as Monel 400 Round Bar, Monel Alloy 400 Round Bar & Nickel Alloy 400 Round Bar. These Monel 400 Forged Bar, Monel 400 Welding Rod & Monel 400 Hollow Bar are particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. This Monel 400 Rod and Nickel 400 Bar is attacked in sulfur-bearing gases above approximately 700° F and molten sulfur attacks the alloy at temperatures over approximately 500° F.
Looking for best price of Monel 400 Hex Rod in India? We have no minimum footage requirements. We will supply the exact amount of Monel 400 Hex Bar you require even if it’s small quantity. Contact Nirmaan Steel – the right Supplier of Monel Alloy 400 Rod near you.
Nirmaan Steel is manufacturer & stockist of Monel 400 bars, Monel 400 Bright Round Metric (BRM), Monel 400 shaft bars for use in Valve Shafts, Piston Shafts, Pump Shaft, Cylinder Shafts, Boat Shafts and Bearing Bars. Monel 400 Drawn bars have greater size accuracy, straightness, and increased tensile and yield strength, as well as improved machinability. In addition to standard Alloy 400 cold drawn bars, it can be supplied as turned and polished, turned ground and polished and drawn ground and polished in shape of square, hexagonal and flat bars. Our custom Monel 400 Forged Bars & Alloy 400 Forged round bars are suited for multiple applications and serve a variety of different industries. These Monel 400 Forged Bar, Alloy 400 Forged stepped shafts, Monel 400 Forged Flat Bars & Monel Alloy 400 Forged Square Bars tend to be stronger than Alloy 400 rolled bars due to the solid forged center that is provided via the forging process.
Our Dealers & Distributors in India and USA arrange complete range of Monel 400 flat bar & Monel 400 Rebar in shortest time as well at best price, because we maintain Monel 400 Bar in the form of Rod, Round Bar, Bright Bar, Flat Bar, Hex Bar, Square Bar, Block, Threaded Bar, Ingot, Shaft, Billet, Straight Forging and Extruded Section in stock for sale, so it saves time & cost to procure any size range in Monel 400 Black Bar stock in rounds, square and flats from any other vendor or Manufacturer of Hot Rolled Monel 400 Round Bar in India. We also offer Monel 400 Bright Round Bar lengths are cut, straightened again and the ends are chamfered before the Monel 400 Bar is polished and tested.
Our online Monel 400 Round Bar Weight Calculator allows you to calculate an estimate of the weight of different sizes of Monel 400 round bars, Monel 400 Cold Drawn Round Bar, Monel 400 Bright Round Bar or Monel 400 Metric Bright Round Bar based on dimensions and shape. Check below table of Monel 400 Bright Bar sizing chart which shows nominal size and provides convenient weight data.
Monel 400 Half Round Bar combines excellent mechanical properties, strength, corrosion resistance, and ease of welding. Alloy 400 Round Bars & Alloy 400 Bright Round Bars are mainly use when the highest level of accuracy and precision are needed along with a bright finish.
Nirmaan Steel is supplier of Alloy 400 Round Rods as Cold Drawn, Centre less Ground & Polished, Peeled, Smooth turned or Rough turned.. We are stocking distributor of Monel 400 Peeled Bar. We offer best price of Alloy 400 Bars in India & Europe. Special price offer on Monel 400 Rectangular Bar and Monel 400 octagonal Bar. Alloy 400 Bright Bar, Alloy 400 Flat Bar and large diameter alloy 400 round bar are available in more than 60 types of thickness & sizes. Buy Monel 400 Bright Ground Bar stock at best price. Compare our Alloy 400 Rod price with Monel Alloy 400 Round Bars price in China.
Table of contents
Looking to buy Alloy 718 Round Bar? Inconel 718 Round Bar?
Check price of Inconel 718 Round Bar in India
Monel 400 round bar Specification
| AMS Number | Alloy | Type | UNS | Cross Ref. Spec | Misc./Shape |
|---|---|---|---|---|---|
| AMS 4675 Bar | Monel 400 | Nickel Copper | N04400 | ASTM B 164 | Bar |
| Grade | Monel 400 – UNS N04400 |
| Specification | ASTM B164 UNS N04400 |
| Monel 400 Round bar size | Diameter: 3mm~800mm |
| Monel 400 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Monel 400 Square bar size | 4mm*4mm~100mm*100mm |
| Monel 400 Flat bar size | Thickness: 2mm~100mm Width: 10mm~500mm |
| Monel 400 Hex Bar size | 2mm~100mm |
| Monel 400 Billet Size | 1/2″ to 495mm Diameter |
| Monel 400 Rectangles Size | 33mm x 30mm to 295mm x 1066mm |
| Finish | Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawn Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar |
| Technique | Monel 400 Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Monel 400 Bar Type | Drawn Bar, Rolled Bar, Forged Bar, GFM Forged Bar, Open Die Bar, Forged Stepped Shafts, Forged Flat Bar, Forged Square Bar |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
Our Monel 400 round bar conforms to NACE MR0175/ISO 15156
Monel 400® bar stock is approved for a variety of industrial, international, MIL-SPEC, and other specifications, including:
- UNS N04400
- ASTM B164
- AMS 4675
- AMS 4730
- ASM 4731
- QQ-N-281
- BS3076NA13
- DIN 17753
- VdTUV 263
Specifications: ASTM B164, AMS 4675, AMS 4730, AMS 4731
Monel Alloy 401 Specifications: UNS N04401, ASTM B164, ASME SB164
International Specifications: QQ-N-281 , BS3076NA13, DIN 17753, VdTUV 263
Monel 400 Bar Stock
Monel 400 Round Bar Types
Monel 400 round bar types are many and their use would depend on the application or the industry in which they would be used. The Density of Alloy 400 Flat Bar is 8.80 g/cm3 (0.318 lb/in.3). Alloy 400 Bar Modulus of Elasticity, (103 ksi) for Tension is 26.0, for Compression is 26.0 and for Torsion is 9.5. The Melting Range of ASTM B164 Monel 400 is 2370-2460 °F (1300-1350 °C). The Curie Temperature of ASTM B164 Alloy 400 is 70-120 °F (21-49 °C). ASTM B164 UNS N04400 Poisson’s Ratio is 0.32. The Tensile Strength of ASME SB 164 N04400 is 75-90 ksi (517-620 MPa). Monel UNS N04400 Bar Yield Strength Hardness (0.2% Offset) is 25-50 ksi (172-345 MPa). Werkstoff 2.4360 Bar is utilized in many fields like chemical processing, marine, etc.
Monel 400 Rectangular Bar
Monel 400 Flat Bar
Monel 400 Square Bar
Monel 400 Rounds
Monel 400 T-Bar
Monel 400 Half-Round Bar
Monel 400 Bright Bar
Monel 400 Hexagonal Bar
Monel 400 Threaded Bar
Monel 400 Rebar
Monel 400 Hollow Bar
Monel 400 Precision Ground Bar
Monel 400 Precision Ground Stock
Monel 400 Triangle bar
Monel 400 Hex Bar
Monel 400 Rod
AMS 4675, AMS 4730, AMS 4731 Monel Alloy 400 Rod, Bar Stock List
| Alloy | Product form | Dimension |
|---|---|---|
| MONEL ALLOY 400 (66 Ni/34 Cu) | Square bar; cold drawn | 25×25 mm, Weight=5.7 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; solution annealed, ground, polished | Dia=6.35 mm, Weight=0.27 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; cold drawn, annealed | Dia=8.0 mm, Weight=0.43 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; drawn, ground | Dia=10.0 mm, Weight=0.7 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; cold drawn, annealed | Dia=12.0 mm, Weight=1.1 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; annealed, peeled | Dia=16.0 mm, Weight=1.9 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot finished, ground, annealed | Dia=20.0 mm, Weight=2.9 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; cold drawn, stress relieved | Dia=25.0 mm, Weight=4.5 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, annealed, peeled | Dia=30.0 mm, Weight=6.4 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, annealed, peeled | Dia=35.0 mm, Weight=8.7 kg/m |
| MONEL ALLOY 400 (66 Ni/34 Cu) | Round bar; extruded, machined, annealed | Dia=40.0 mm, Weight=11.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, annealed, peeled | Dia=45.0 mm, Weight=14.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, peeled, annealed | Dia=50.0 mm, Weight=17.6 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, peeled, annealed | Dia=60.0 mm, Weight=25.6 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot finished, annealed, peeled | Dia=65.0 mm, Weight=30.0 kg/m |
| MONEL ALLOY 400 (66 Ni/34 Cu) | Round bar; forged, peeled, annealed | Dia=75.0 mm, Weight=40.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; forged, peeled, annealed | Dia=80.0 mm, Weight=44.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; forged, annealed, peeled | Dia=85.0 mm, Weight=49.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, peeled, annealed | Dia=100.0 mm, Weight=71.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; forged, peeled, annealed | Dia=115.0 mm, Weight=92.0 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot worked, peeled, annealed | Dia=127.0 mm, Weight=109 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot finished, annealed, peeled | Dia=130.0 mm, Weight=118 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot finished, annealed, peeled | Dia=140.0 mm, Weight=133 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; annealed, peeled | Dia=150.0 mm, Weight=153 kg/m |
| MONEL ALLOY 400 (64Ni/34 Cu) | Round bar; forged, peeled, annealed | Dia=165.0 mm, Weight=190 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; annealed, forged | Dia=170.0 mm, Weight=196 kg/m |
| ALLOY 400 (66 Ni/34 Cu) | Round bar; hot finished, annealed, peeled | Dia=200.0 mm, Weight=271 kg/m |
| MONEL ALLOY 400 (66 Ni/34 Cu) | Hexagon bar | 48.0 mm a/f, Weight=17.18 kg/m |
|
Monel® alloy 400 Rod, Diameter: 3.0mm, Temper: Annealed |
|
Monel® alloy 400 Rod, Diameter: 6.35mm, Temper: As drawn |
|
Monel® alloy 400 Rod, Diameter: 12.7mm, Temper: As drawn |
|
Monel® alloy 400 Rod, Diameter: 20mm, Temper: Annealed |
|
Monel® alloy 400 Rod, Diameter: 40mm, Temper: Annealed |
Monel 400 Precision ground bar is manufactured through induction hardening. Induction hardening is a non-contact heating process which uses electromagnetic induction to produce the required heat. Monel 400 Centerless ground bar is typically produced by turning and grinding the surface to a specified size.
Monel 400 Precision Ground Bar, also known as ‘Turned Ground and Polished’ shafting, refers to round bars made with fine precision and high-quality steel. They are polished to ensure flawless and perfectly straight surfaces. The manufacturing process is designed for extremely close tolerances for surface finish, roundness, hardness, and straightness which ensures a long service life with reduced maintenance.Monel 400 Round Bar Price
| Monel Alloy 400 Round Bar Price List | PACK QTY | PRICE |
|---|---|---|
| Price of Alloy 400 Round Bar 10.0mm dia x 500mm long | 1 | £65.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 500mm long | 2 | £96.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 500mm long | 3 | £128.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 500mm long | 4 | £154.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 500mm long | 5 | £176.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 1000mm long | 1 | £81.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 1000mm long | 2 | £129.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 1000mm long | 5 | £267.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 2000mm long | 1 | £122.00 |
| Price of Alloy 400 Round Bar 10.0mm dia x 2000mm long | 2 | £202.00 |
| Price of Alloy 400 Hex Bar / Rod 10mm (A/F) x 1000mm Length | 1 | $101.16 |
| Price of Alloy 400 Hex Bar / Rod 10mm (A/F) x 1000mm Length | 3 | $258.52 |
| Price of Alloy 400 Hex Bar / Rod 10mm (A/F) x 1000mm Length | 5 | $368.11 |
| Price of Alloy 400 Hex Bar / Rod 10mm (A/F) x 2000mm Length | 1 | $182.65 |
| Price of Alloy 400 Hex Bar / Rod 10mm (A/F) x 2000mm Length | 3 | $427.12 |
Please note: Price is subject to change without any prior notice.
Click here to check complete (grade & size wise)
Monel 400 bar properties
ASTM B164 Monel 400 Bar Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | BS | EN |
|---|---|---|---|---|---|---|---|
| Monel 400 | 2.4360 | N04400 | МНЖМц 28-2,5-1,5 | NU-30M | NW 4400 | NA 13 | NiCu30Fe |
Monel Alloy 400 Round, Bright, Hex, Threaded Bar Chemical Composition
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S |
|---|---|---|---|---|---|---|---|---|
| Monel 400 | 63.0 min | 1.0 – 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.50 max | 0.02 max |
Monel Alloy 400 Round Bars Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40 % |
Monel 400 Bar Sizes
|
Nickel Ann – Round * CG – Centerless Ground HR RT – Hot Rolled Rough Turned |
3/16 CG Bars | 2 CG Bars |
| 1/4 CG Bars | 2-1/4 CG Bars | |
| 5/16 CG Bars | 2-1/2 CG Bars | |
| 3/8 CG Bars | 2-3/4 CG Bars | |
| 1/2 CG Bars | 3 CG Bars | |
| 5/8 CG Bars | 3-1/4 CG Bars | |
| 3/4 CG Bars | 3-1/2 CG Bars | |
| 13/16 CG Bars | 4 HR RT Bars | |
| 7/8 CG Bars | 4-1/2 HR RT Bars | |
| 1 CG Bars | 5 HR RT Bars | |
| 1-1/8 CG Bars | 6 HR RT Bars | |
| 1-1/4 CG Bars | 7 HR RT Bars | |
| 1-3/8 CG Bars | 8 HR RT Bars | |
| 1-1/2 CG Bars | 9 HR RT Bars | |
| 1-3/4 CG Bars | 10 HR RT Bars |
An estimated delivery time location wise for Monel 400 Round Bar
| Country | Days | Country | Days |
|---|---|---|---|
| USA | 45 | Canada | 45 |
| Australia | 30 | UK | 35 |
| Malaysia | 15 | Poland | 15 |
| Iran | 7 | Singapore | 14 |
| Vietnam | 20 | Albania | 20 |
| UAE | 15 | Thailand | 20 |
| Nigeria | 40 | Ethiopia | 40 |
| Turkey | 30 | Tanzania | 30 |
| Bahrain | 15 | Kenya | 40 |
| Libya | 40 | Syria | 40 |
| Zambia | 40 | Egypt | 40 |
| Italy | 40 | India | 7 |
| Saudi Arabia | 15 | Qatar | 15 |
| Namibia | 40 | Indonesia | 20 |
| South Africa | 40 | Australia | 40 |
| Uganda | 40 | Angola | 40 |
| Kazakhstan | 20 | Algeria | 20 |
Monel 400 Round Bar, 400 Monel Rods, Alloy 400 Hex Bar Supplier
