Inconel X750 plate suppliers
Alloy X750 Sheet, N07750 plate suppliers in Mumbai
Buy Inconel X750 coil, nickel alloy 750 sheets, astm b637 uns n07750 at best price in India
Inconel X750 Plate
Inconel X750 Sheet
Inconel X750 Coil
Inconel X750 Plate has good resistance to corrosion and oxidation along with high tensile and creep rupture properties at temperature up to 1300ºF (700ºC). Alloy X750 Plate is designated as UNS N07750 and Werkstoff Number 2.4669. Inconel Alloy X750 Plate also known from its specification like as Nicrofer 7016 Plate, Superimphy 750 Plate, Haynes X750 Plate, Pyromet X750 Plate, and Udimet X750 Plate, Nickelvac®X750 Plate, Nicorros® 7016 Plate. Cutting of Inconel X750 Coil is often done with a waterjet cutter. Internal threads can also be cut by single point method on lathe, or by threadmilling on a machining center. Inconel X750 Flat Shim, Inconel X750 Perforated Plate, Inconel X750 Cold rolled Plate, Inconel X750 Foil, Inconel X750 Rolling Sheets & Inconel X750 Rolling Plate can be cold formed by standards methods.
Looking for best price of Inconel X750 Clad Plate in India? We have no minimum footage requirements. We will supply the exact amount of Inconel X750 Shim you require even if it’s small quantity of Inconel X750 Strip. Contact Steel Tubes India- the right supplier of Inconel X750 Flat Sheet near you.
Nirmaan Steel offers one of the widest ranges of Alloy X750 sheet and Alloy X750 plate in various qualities, sizes and grades which are equivalent to Inconel X750 Sheet & Inconel X750 Plate (2mm to 12mm). Inconel X750 Sheet is available in thicknesses ranging from .016 to .156″. Large size Inconel X750 plate will also diminish the size of the undesirable heat-affected zone caused by welding. We also stock & supply extra large-size Inconel X750 Sheets, thin and ultra-thin gauge Inconel Alloy X750 strip and foil products, rolled down to 2 microns.
Superior technology as well as extensive quality control from steelmaking to finishing assure the stable production of Inconel X750 Hot Rolled Plates in uniformly of excellent quality. We apply the process of surface finishing to our Inconel X750 Polished Plate by pickling or buff-polishing. Inconel X750 Strips levels of finishing & cut can be adjusted according to your requirements. Inconel X750 Plate is available in the form of Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Inconel X750 Plate Weight Calculator allows you to calculate an estimate of the weight of different sizes of Inconel X750 plates based on dimensions and shape. Inconel X750 Shim is sold in either 300mm or 600mm rolls and sheet form. The thin material can be used in power plants, nuclear plants or gas and oil refineries.
Our Dealers & Distributors in India arrange complete range of Inconel X750 plates in shortest time as well at best price, because we maintain Inconel X750 Sheet in stock for sale, so it saves time & cost to procure any size range in Bright annealed Inconel X750 sheet from any other vendor or Manufacturer of mirror finish Inconel X750 plate in India.
Distributor of Inconel X750 Clad Plate, Inconel X750 Sheet in Mumbai, India
Inconel 718 Flat Shim is designated as UNS N07718 and Werkstoff Number 2.4668. Inconel® 718 Plate is also known as Nicrofer 5219 Plate, Superimphy 718 Plate, Haynes 718 Plate, Pyromet 718 Plate, Supermet 718 Plate. and Udimet 718 Plate.
Looking for best price of 718 Inconel Plate in India? We have no minimum footage requirements. We will supply the exact amount of Inconel 718 Foil you require even if it’s small quantity of 2.4668 Inconel 718 sheet. Contact Steel Tubes India- the right supplier of Inconel UNS N07718 Plate near you.
Nirmaan Steel offers one of the widest ranges of Alloy 718 sheet and Alloy 718 plate in various qualities, sizes and grades which are equivalent to Inconel 718 Sheet & Inconel 718 Plate (2mm to 12mm). Inconel 718 Sheet is available in thicknesses ranging from .016 to .156″. Large size Inconel 718 plate will also diminish the size of the undesirable heat-affected zone caused by welding. We also stock & supply extra large-size Inconel 718 Sheets, thin and ultra-thin gauge Inconel Alloy 718 strip and foil products, rolled down to 2 microns.
Superior technology as well as extensive quality control from steelmaking to finishing assure the stable production of 718 Inconel Plate in uniformly of excellent quality. We apply the process of surface finishing to our Inconel 718 Polished Plate by pickling or buff-polishing. Inconel 718 Strips levels of finishing & cut can be adjusted according to your requirements. Inconel 718 Plate is available in the form of Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Inconel 718 Plate Weight Calculator allows you to calculate an estimate of the weight of different sizes of Alloy 718 Plate based on dimensions and shape. Inconel 718 Shim is sold in either 300mm or 600mm rolls and sheet form. The thin material can be used in power plants, nuclear plants or gas and oil refineries.
Looking for Inconel 718 Sheet Suppliers UK? We have our dealers & distributors in UK, USA, Sweden, Israel, Germany, Russia, France, Italy, Saudi Arabia, Malaysia, Canada, UAE, Singapore, Oman, Kuwait, Qatar, Iran, Indonesia & Australia arrange complete range of Inconel 718 plate in shortest time as well at best price, because we maintain Inconel 718 Sheet in stock for sale, so it saves time & cost to procure any size range in Bright annealed Inconel 718 sheet from any other vendor or Manufacturer of Alloy 718 Foil in India.
Table of contents
Looking to buy Inconel Sheet? Inconel Plate?
Check price of Inconel Plate in India
Inconel X750 Tube Price in India
Inconel X750 Sheet Price List
| Inconel X750 Sheet Price | Origin | Price in INR (per kg) | Price in USD (per kg) | Price in Euro (per kg) | Others |
|---|---|---|---|---|---|
| Inconel X750 Sheet Price in India | Indian | Rs 5500/- | $80 | €68 | Cut to Size |
| Inconel X750 Sheet Price in Japan | Japanese | Rs 6200/- | $91 | €78 | Fix Length |
| Inconel X750 Sheet Price in UK / Europe | European | Rs 6900/- | $101 | €87 | Fix Length |
| Inconel X750 Sheet Price in USA | USA | Rs 7500/- | $110 | €94 | Fix Length |
Please note: Price is subject to change without any prior notice.
Click here to check complete (grade & size wise)
Inconel X750 Sheet Stock, X750 rolling sheets supplier, Inconel alloy X750 flat sheet suppliers in India
Alloy X750 plate Specification
Inconel Alloy X-750 AMS 5542, AMS 5598
- UNS N07750
- AMS 5598
- AMS 5542
- ASTM B 637
- ASME SB 637
- W.Nr 2.4669
- PWA-LCS
- GE-S400/1000
- RR SABRe Edition 2
- DFARS Compliant
Common Trade Names
- ATI X-750 (™ Allegheny Technologies)
- Inconel Alloy X-750 (® Special Metals)
| Inconel X750 Sheet ASTM Specification | ASTM B637 UNS N07750, ASME SB637, AMS 5542, AMS 5598, AMS 5667, AMS 5668, AMS 5670, AMS 5671, AMS 5747, ASTM-B-637, UNS N07750, B50A714, B50A151, MIL-N-7786 |
|---|---|
| Alloy X750 Plate Specification | MSRR, AMS, BS, ASTM B637 / ASME SB637 |
| Inconel X750 Plate Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36″ x 120″ or 48″ X 144″, Cut to size available |
| Inconel X750 Plate Thickness | 0.1mm to 100 mm Thk |
| Inconel X750 Plate Width | 10-2500mm |
| Inconel X750 Sheet AMS | AMS 5542, AMS 5598, AMS 5667, AMS 5668, AMS 5670, AMS 5671, AMS 5747 |
| Inconel X750 Sheet Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper | Annealed |
| Condition | Polished on both sides |
| Inconel X750 Plate Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Inconel X750 Plate Stock in form of | Alloy X750 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| High Quality Inconel X750 Sheet |
|
| Inconel X750 profiling |
To provide a full profiling service we use numerous profiling methods including:
|
| Specialized in |
|
Steel Tubes India offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing.
Inconel X750 Plate Properties & Applications
With regards to Inconel X750 plate properties & applications, Inconel X750 plate properties are that, up to a temperature of 700 ºC (1300 ºF), it has creep rupture and high tensile strength. Inconel X750 plates offer superb resistance to oxidation and corrosion. Inconel X750 plates are used in many applications like rocket engines, aircraft structures, gas turbines, tooling structures, pressure vessels, high-temperature bolts and springs, nuclear reactors, etc.
Types of Inconel X750 Plate
Inconel X750 2B Sheet
Decorative 8K Mirror Inconel X750 Sheet
Hairline Inconel X750 Sheet
No.4 Inconel X750 Sheet
Inconel X750 Plate
Inconel X750 Sheet
Inconel X750 Coil
Inconel X750 Clad Plate
Inconel X750 Strips
Inconel X750 Shim Stock
Inconel X750 Rolling Sheets
Inconel X750 Flat Sheet
Inconel X750 Rolling Plate
Inconel X750 Flat Shim
Inconel X750 Perforated Plate
Inconel X750 Polished Plate
Inconel X750 cold rolled sheet
Inconel X750 hot rolled plate
Alloy X750 Plate
Alloy X750 Sheet
Inconel X750 Quarto Plate
Inconel X750 Precision Strip
Alloy X750 Cold Rolled Coil, Strip And Sheet
Alloy X750 Hot Rolled Coil, Strip And Plate
Difference between Inconel X750 Sheet, Plate & Foil
Here are few points to recognised sheet, plate or foil:
If thickness greater than 6.35 mm is called a Inconel X750 Plate.
If thickness greater than 0.15 mm and less than 6.35mm is called a Inconel X750 Sheet.
If thickness less than 0.15mm is then its a Inconel X750 Foil.
Inconel X750 Plate Properties
Inconel X750 Plate mechanical properties
Inconel X-750 Sheets, Plates & Coils Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Inconel X-750 | 2.4669 | N07750 |
Inconel Alloy X-750 Sheets & Plates Chemical Composition
| Grade | Ni | Cr | Al | C | Mn | Ti | Cu | Si | S |
|---|---|---|---|---|---|---|---|---|---|
| Inconel X-750 | 70.0 min | 14.0 – 17.0 | 0.40 – 1.0 | .08 max | 1.00 max | 2.25 – 2.75 | 0.50 max | .50 max | .01 max |
Inconel Alloy X-750 Strips, Sheets & Plates Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.28 g/cm3 | 1430°C | 1267 MPa | 868 MPa | 25 % |
Inconel X750 Sheet Sizes
| Sizes in Inches | Sizes in mm |
|---|---|
| .125″ | 3.18mm |
| .134″ | 3.40mm |
| .156″ | 3.96mm |
| .187″ | 4.75mm |
| .250″ | 6.35mm |
| .312″ | 7.92mm |
| .375″ | 9.53mm |
| .500″ | 12.7mm |
| .625″ | 15.9mm |
| .750″ | 19.1mm |
| .875″ | 22.2mm |
| 1″ | 25.4mm |
| 1.125″ | 28.6mm |
| 1.250″ | 31.8mm |
| 1.500″ | 38.1mm |
| 1.750″ | 44.5mm |
| 2″ | 50.8mm |
| 2.500″ | 63.5mm |
| 3″ | 76.2mm |
Metric Dimensions
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Imperial Dimensions
| Surface finish | Gauge (in) | Width (in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | max. 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Polished (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
An estimated delivery time location wise for Inconel X750 Sheet & Plate
| Country | Days | Country | Days |
|---|---|---|---|
| USA | 45 | Canada | 45 |
| Australia | 30 | UK | 35 |
| Malaysia | 15 | Poland | 15 |
| Iran | 7 | Singapore | 14 |
| Vietnam | 20 | Albania | 20 |
| UAE | 15 | Thailand | 20 |
| Nigeria | 40 | Ethiopia | 40 |
| Turkey | 30 | Tanzania | 30 |
| Bahrain | 15 | Kenya | 40 |
| Libya | 40 | Syria | 40 |
| Zambia | 40 | Egypt | 40 |
| Italy | 40 | India | 7 |
| Saudi Arabia | 15 | Qatar | 15 |
| Namibia | 40 | Indonesia | 20 |
| South Africa | 40 | Australia | 40 |
| Uganda | 40 | Angola | 40 |
| Kazakhstan | 20 | Algeria | 20 |
Inconel alloy X750 strip distributor, Inconel X750 cold rolled plate stockist in Mumbai
