ASTM A312 TP304L Stainless Steel Pipe
304L Seamless Tubing, 304L Stainless Steel Tube suppliers
SS 304L Erw Pipe, Din 1.4306 / 1.4307 AISI 304L Needle Tube, AMS 5566 Type 304L Rectangular Welded Pipes Price in India
Stainless Steel 304L Tube
304L Stainless Steel Pipe
SA312 TP304L Tubing
Stainless Steel 304l Seamless Round Tubing Suppliers
Are you searching for the best stainless steel 304L seamless round tubing suppliers? If so, you can be sure that your search has come to an end. We are one of the oldest and also the most reputed suppliers of TP304L Stainless Steel Pipe. The Specific Heat Capacity of a312 tp304l pipe is 0.12 BTU/lb-°F (0.5 J/g-°C). Stainless steel 304L has a Solidus of 2550 °F (1400 °C). The Liquidus of SS 304l pipe is 2640 °F (1450 °C). The Magnetic Permeability of stainless steel 304L is 1.008. The Density of 304l seamless tube is 0.289 lb/in³ (8 g/cc). Nirmaan Steel also provide upto 16 grit polish on TP304L Pipe.
304L Stainless Steel Tube has a slight, but noticeable, reduction in key mechanical performance characteristics compared to the “standard” SS 304L. 304L Stainless Steel Pipe is suitable in the “as-welded” state, even in severe corrosive environments. SA312 TP304L is the most versatile and widely used alloy in the stainless steel family. 304L Seamless Tubing is more resistant to carbide precipitation and can be heated into the above temperature range. Stainless Steel 304L Seamless Round Tubing grade of stainless steel exhibit good machinability and have excellent weld-ability characteristics with or without the addition of filler metals. SS 304L Erw Pipe is an even lower carbon version of 304 stainless steel and can be used in more corrosive environments such as salt water and chemical containers.
We at Nirmaan Steel stock various sizes of Din 1.4306 / 1.4307 AISI 304L Pipes up to the biggest 4 inches in diameter in 20 feet long. 304L Stainless Steel Welded Tubes are available in bright polished finish. We supply 304L Stainless Steel Threaded Pipe up to the biggest 4 inches in wall opening in 20 feet long. SS 304L Needle Tube are available in both bright polished and hairline finish. We also stock AMS 5566 Seamless/ Welded Tube up to the biggest 4 inches in wall opening in 20 feet long. 304L Stainless Steel Oval Tubing are available in both bright polished and hairline finish.
Nirmaan Steel in govt recognised exporter of SS 304L Gas Tube in India. We manufacture of all types on 304L Stainless Steel Rectangular Tube. We have supplied ASTM A269 TP304L to Gasco, ASTM A249 TP304L Polish Tube to Saudi Aramco, Stainless Steel 304L Coiled Tube to Oman, ASTM A312 TP304L Coiled Tubing to KNPC, SA312 TP304L Tubes to Qatar Gas, Stainless Steel 304L Seamless Pipe to Dubai, Stainless Steel 304L Pipes to leading oil & gas company in Iraq, ASTM A249 TP 304L Stainless Steel High Pressure Tube to South Africa, 304l square tube to North America, 304l round tube to United Kingdom and 304l stainless tubing to UAE. We have more than 14 years of experience in supplying ss 304l schedule 40 pipe. Our highly experienced team can help you to buy right AISI 304l pipe.
If you are looking to buy High quality assured Stainless Steel 304L capillary tube, Stainless Steel 304L Square Tubing or Stainless Steel 304L Polished Tube at best price in India, send an email to nirmaansteel@gmail.com, we will send you the Free Quote & recent price of Stainless Steel 304L precision tubes, Stainless Steel 304L Welded Tube, Stainless Steel 304L instrumentation tubes, Stainless Steel 304L Oval Tube along with inspection & delivery schedule.Nirmaan Steel is a Govt. of India recognised Exporter of Stainless Steel 304L Mirror Tube in India and shipping to Europe, Trinidad & Tobago, Singapore, Qatar, Ethiopia, United Arab Emirates, Oman, Malaysia, Kuwait, Canada, Australia, United States, United Kingdom, St. Helena, South Africa, Philippines, Ireland, South Korea, Iraq, Norway, Finland, Egypt, Netherlands, Nigeria, Ghana, Saudi Arabia, Denmark, Iran, Kenya, Sweden, Thailand, Indonesia, New Zealand, Belgium, Pakistan, Taiwan, Hong Kong, Greece & Germany since 2002. SS 304L Needle Tube, SS 304L Round Tube and Stainless Steel 304L hydraulic tube are available in different sizes, diameter & wall thickness.
Table of contents
- ASTM A249 Tp304l Tube Price in India
- ASTM A312 TP304L Tube Specification
- 304L Stainless Steel Tubing Tolerances
- Stainless Steel 304L Tube Stock
- ASTM A213 TP304L tube properties
- SA213 TP 304L Tube Sizes
- 304L Stainless Steel Pipe Weight
- 304L Stainless Steel Pipe Pressure Rating
- Difference Between Inconel and Stainless Steel
- Type 304L Stainless Steel tube dimensions
Looking to buy 304 Stainless Steel Tube? 304 Stainless Steel Tubeing?
ASTM A249 TP304l Tube Price in India
If you are looking for the best ASTM A249 TP304L tube price in India, rest assured you will get that right here, at this website. The Chemical Composition of ASTM A249 TP304L is Mn Max 2, C Max 0.03, P Max 0.045, Cr 18 – 20, S Max 0.03, Ni 8 – 12 and Si Max 1. The Maximum Service Temperature (Air, Intermittent Service) is 1600 °F (870 °C). The Maximum Service Temperature (Air, Continuous Service) is 1700 °F (925 °C). ASTM A249 TP304L has an Elongation at Break of 58%. The Ultimate Tensile Strength of ASTM A249 TP304L is 81800 psi (564 MPa).
| SS 304L Pipe Price Per Kg | Origin | Price in INR (per kg) | Price in USD (per kg) | Price in Euro (per kg) | Others |
|---|---|---|---|---|---|
| ASTM A312 TP304L Tube Price in India | Indian | Rs 195 – 295/- as per your requirement sizes | $2.85 | €2.43 | Cut to Size |
| ASTM A213 TP304L Tube Price in Japan | Japanese | Rs 250 – 350/- as per your requirement sizes | $3.65 | €3.12 | Fix Length |
| SA213 TP 304L Tube Price in UK / Europe | European | Rs 300 – 400/- as per your requirement sizes | $4.38 | €3.74 | Fix Length |
| S30403 Stainless Steel Tube Price in USA | USA | Rs 350 – 450/- as per your requirement sizes | $5 | €4.37 | Fix Length |
ASTM A312 TP304L Stainless Steel Pipe Standards
ASTM A312 TP304L stainless steel pipe standards include straight-seam welded pipes, seamless pipes and cold worked welded pipes, that are meant for use in general corrosive service and high-temperatures. The Modulus of Elasticity of 304L stainless steel is 28000 – 29000 ksi (193 – 200 GPa). 304L stainless steel has a Magnetic Permeability of 1.008. The Melting Point of 304L stainless steel is 1400 – 1450 °C (2550 – 2640 °F). The Maximum Service Temperature (Air, Intermittent Service) of AMS 5566 Tubing is 1600 °F (870 °C) and the Maximum Service Temperature (Air, Continuous Service) is 1700 °F (925 °C).
ASTM A312 TP304L TUBE SPECIFICATION
| Standards | ASTM A213, ASTM A249, ASTM A269, ASME SA213, ASME SA249, ASME SA269, EN 10216-5 TC1 / TC2, PED 97/23/EC, AD 2000, NACE MR0175/ISO 15156 |
|---|---|
| 304 Seamless Aerospace Tubing | AMS 5564, AMS 5565, AMS 5567, AMS 5569, AMS 5095 (Canceled & non-current specs include AMS-T-6845, MIL-T-6845, AMS-T-8504, MIL-T-8504, AMS-T-8506, MIL-T-8506) |
| Typical Manufacturing Specifications |
|
| Stainless Steel 304L Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Stainless Steel 304L Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| SS 304L Pipe Schedule | SCH5, SCH5S, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Stainless Steel 304L tubing wall thickness | 0.020″–0.220″, (special wall thicknesses available) |
| 304L tube Length | Single Random, Double Random, Standard & Cut length |
| 304L Stainless Steel Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | Straight, Coiled, Seamless, Round Pipes/ Tubes, Square Pipes/ Tubes, Rectangular Pipe/ Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Stainless Steel 304L Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Electropolished | (EP) Electropolished for Ultra High Purity Systems |
| Non-Electropolished | (BA) Bright Annealed or (AP) Annealed & Pickled for High-Purity, (CPDS) Cleaned for Oxygen Grade Service or Corrosive Systems |
| I.D. Surface Finish Options | 5, 7 & 10 µin. Ra |
| JIS | 8A to 250A |
| Tolerances | In accordance with: ASTM: A269 & A632, JIS: G 3459 |
| End | Plain End, Beveled End, Treaded, Ends are suitable for orbital welding |
| Marking | All 304L Stainless Steel tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | Stainless Steel 304L Capillary Tube & Other Odd Size Stainless Steel 304L Heat Exchanger & Condenser Tubes Stainless Steel 304L Hydraulic tubing with OD up to 50.8 mm (2.0 in.) are delivered in bright annealed condition Stainless Steel 304L hydraulic tube with OD larger than 50.8 mm are supplied in the annealed and pickled condition, or in polished condition |
| Marking & Traceability | Each Stainless Steel 304L Tubing is traceable to its producing mill and heat by an identification number etched within 24″ (610mm) of one end. |
| Test Certificate | Manufacturer Test Certificate according to EN 10204 3.1 B Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Testing & Inspection | Visual Inspection • Surface roughness measurement • Helium-leak testing • Scanning Electron Microscopy (SEM) • Auger Electron Microscopy (AES) • Electron Spectroscopy for Chemical Analysis (ESCA or XPS) • Particle testing • Moisture testing |
| We can also cut, thread, and groove Stainless Steel 304L Tubes to meet your specifications | |
304l Stainless Steel Tubing Applications
The Melting Point of stainless steel 304L is 2550 – 2640 °F (1400 – 1450 °C). The Charpy impact of stainless steel 304L is 159 ft-lb (216 J). The Modulus of Elasticity of stainless steel 304L is 28000 – 29000 ksi (193 – 200 GPa). 304L stainless steel tubing applications are many and some of these are pressure vessels, dairy equipment, chemical equipment, flexible metal hose, oil well filter screens, bellows, nuclear vessels, cooling coils, paper industry, beer barrels, shipping drums, refrigeration equipment, coal hopper linings, textile dyeing equipment, feedwater tubing, food processing equipment, sanitary fittings, evaporators, etc.
Stainless Steel 304L Tube Wall Thickness
| 0.28 | = | .028″ Thick |
| 0.35 | = | .035″ Thick |
| 0.39 | = | .039″ Thick |
| 0.49 | = | .049″ Thick |
| 0.65 | = | .065″ Thick |
| 0.83 | = | .083″ Thick |
| 1.09 | = | .109″ Thick |
304L Stainless Steel Tubing Tolerances:
The Stainless Steel 304L tubes outer diameter (OD) are according to ASTM A269/A213. Stainless Steel 304L Tubing Tolerance specifications are as per below:
| Stainless Steel 304L Tube OD | Stainless Steel 304L Tube Tolerance |
|---|---|
| 4mm to 25mm | +/- 0.08mm |
| 25mm to 38mm | +/- 0.15mm |
| 38mm to 60mm | +/- 0.20mm |
| 60mm and above | +/- 0.25mm |
Types of Stainless Steel 304L Tube stock
Stainless Steel 304L Coiled Tubing
304L Stainless Steel Capillary Tube
ASTM A312 TP304L ‘U’ Shaped tubing
ASTM A213 TP304L Gas Tube Ar 15 supplier
SA213 TP 304L seamless tubing
Type 304L Stainless Steel Thin Wall tube
S30403 Stainless Steel Furnace Tube
SS 304L Gas Tube
ASTM A312 gr TP 304L Heat Exchanger Tubes
SA213 TP 304L boiler tube
ASTM A269 TP304L welded tubing
ASTM A249 TP304L Square Tubing
SS 304L Hollow Section
ASTM A358 TP304L Rectangle Tube
ASME SA213 TP304L tubing
304L Stainless Steel Filter Tube
SA 688 TP304L Slotted / Groove Pipe
304L Stainless Steel Flue Pipe
304L Welded Stainless Steel Pipe
304L Stainless Steel Oval Pipe/ Elliptical Pipe
Polished 304L Stainless Steel Tube
Manufacturer and supplier of Stainless Steel 304L Pipes & Tubes
| Type 304L Stainless Steel Polished Pipes | Polished 304L Stainless Steel Tubing |
| 304L Stainless Steel Lined Pipe | Corrugated 304L Stainless Steel Tube (CSST) for Gas |
| SA 688 TP304L Woven Mesh Tube | SA249 TP304L Instrumentation Tubing |
| ASTM A358 TP304L Polished Tubing | 304L Stainless Steel Ornamental Tube |
| Stainless Steel 304L Exhaust Pipe | 304L Stainless Steel Spiral Pipe |
| SS 304L Welded Tubes | Stainless Steel Inox 304L Capillary Tubing |
| ASTM A312 TP304L Coiled Tubing | Ams 5566 Seamless Tube |
| ASTM A312 gr TP 304L Aerospace tubes | Ams 5566 High Pressure Tube |
| SA213 TP 304L Sighting Tube | Ams 5566 1/8hd Seamless Tubing |
| ASTM A312 TP304L Elliptical and Oval Tubes | AMS 5569 Rectangular Tube |
| ASTM A213 TP304L Condenser Tube | AMS 5617 1/4Hd Seamless Aero engine tubes |
| ASTM A269 TP304L straight tube boiler | AMS G585 Welded furnace tube |
| ASTM A249 TP304L Mirror Tube | AMS 5566 1/8hd Welded Tubing, High-Pressure Hydraulic |
| UNS S30403 Pitor Tube stockist | Stainless Steel 304L Seamless Round Tubing |
| ASME SA213 TP304L Perforated Tube | WERKSTOFF NR. 1.4306 / 1.4307 Flexible Tube |
| En 1.4306 / 1.4307 / Aisi 304L Thick Wall Tube | 304L Stainless Steel Threaded Pipe |
| Stainless Steel 304L Ornamental Pipe | Stainless Steel 304L Fin Tube / Finned Tube |
| Schedule 10 Type 304L Stainless Steel Pipe | Schedule 40 Type 304L Stainless Steel Pipe |
| 304L Stainless Steel Threaded Pipe | SAE 30304L Stainless Steel Rectangular Tube |
| JIS SUS304L Seamless Tubes | 304L SS Round Tube |
| SA 688 TP304L Finned Tube | SS 304L Dom Tube |
| Din 1.4306 / 1.4307 AISI 304L Perforated Exhaust Tube | Stainless Steel 304L Hypodermic Tubing |
| Din W-Nr. 1.4306 / 1.4307 Aisi 304L Corrugated Tube | SS 304L Honed Tube |
| Material 1.4306 / 1.4307 Aisi 304L Slotted Handrail Tube | SA213 TP304L Thin Wall Tube |
| SS 2332 Stainless Steel U Shaped Tube | 304L Stainless Steel Square Tube Mirror Finish |
| Din 1.4306 / 1.4307 Material Vacuum Tube | WERKSTOFF NR. 1.4306 / 1.4307 Coaxial Tube |
| 304L Stainless Steel Rectangular Pipe | 304L Stainless Steel Hypodermic Tubing for Medical Needle |
| Ultra-High Purity Electropolished Stainless Steel 304L Tube | Thin Wall Stainless Steel 304L Tube |
| 1.4306 / 1.4307 Instrument Tubing | 304L Stainless Steel Square Tubing |
| High-pressure 304L Stainless Steel Water Pipe | SA258 TP304L Hexagonal Pipe |
| Jis 304L Stainless Steel Coil Tubing | Stainless Steel 304L Boiler Tube |
| Din 1.4306 / 1.4307 Stainless Steel Annealed Tubing | SA269 TP304L Coil Tubing Heat Exchanger |
| SAE J405 Uns S30403 Thin Wall Tubing | 304L Stainless Steel Metric Tubing |
| 304L Stainless Steel Seamless Square Tubing | Large Diameter 304L Stainless Steel Tube |
ASTM A213 TP304L Tube Properties
SA213 TP 304L Pipes mechanical properties & chemical composition
Type 304L Stainless Steel Tube Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304L | min. | – | – | – | – | – | 18.0 | – | 8.00 | – |
| max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | – | 12.00 | 0.10 |
S30403 Stainless Steel Tubes Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304L | 485 | 170 | 40 | 92 | 201 |
Stainless Steel 304L Tube Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/ºC) | Thermal Conductivity (W/m.K) | Specific Heat 0-100ºC (J/kg.K) | Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-100ºC | 0-315ºC | 0-538ºC | at 100ºC | at 500ºC | |||||
| 304L | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Equivalent Grades for 304L Stainless Steel Tubes
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | GOST | ||
|---|---|---|---|---|---|---|---|---|
| BS | En | No | Name | |||||
| 304L | S30403 | 304S31 | 58E | 1.4306 / 1.4307 | X2CrNi 18-10 | 2332 | SUS 304L | 03X18H11 |
STAINLESS STEEL 304L TUBES MECHANICAL PROPERTIES
Properties for 2332 Sweden Stainless steel tubing .125″ OD or larger with .015″ wall or heavier.
| Alloy | Temper | Tensile Strength KSI | Yield Strength KSI | Minimum Elongation in 2″ (%) | Rockwell Hardness* |
|---|---|---|---|---|---|
| 304L | Annealed | 100 max. | 25-45 | 35 | B 90 max. |
| Half Hard | 115-140 | 70-110 | 15 | B 93 – C 20 | |
| Full Hard | 140 min. | 110 min. | 7 | C 22 min. |
| Types | Out diameter | Sizes | Length |
|---|---|---|---|
| NB Sizes (In stock) | .0035″ – 8″ | 1/8″, 1/4″, 3/8″, 1/2″, 5/8″, 3/4″, 1″, 1.25″, 1.5″, 2″, 2.5″, 3″, 4″, 5″, 6″ | Cut to length |
| Stainless Steel 304L Seamless Tube (Custom Sizes) | 6.35 mm OD To 101.6 mm OD | As per requirement | Cut to length |
| Stainless Steel 304L Welded Tube (ERW Tube) (In Stock + Custom Sizes) | 6.35 mm OD To 152 mm OD | As per requirement | Cut to length |
TP 304L Stainless Steel Pipes & Tubing Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 304L | 1.4306/1.4307 | S30403 | SUS 304L | 304S11 | 03X18H11 | Z2CN18-09 | X2CrNi 18-9 / X2CrNi 19-11 |
Stainless Steel 304L Seamless Tubes Surface Finish
| Surface Finish | Internal Surface(ID) Roughness Average(RA) | Exterbal Surface(OD) Roughness Average(RA) | ||
|---|---|---|---|---|
| µ inch | µm | µ inch | µm | |
| AP Annealed & Pickled | Not defined | Not defined | 40 or Not defined | 1.0 or Not defined |
| BA Beight Annealed | 40,32,25,20 | 1.0,0.8,0.6,0.5 | 32 | 0.8 |
| MP Mechanical Polish | 40,32,25,20 | 1.0,0.8,0.6,0.5 | 32 | 0.8 |
| EP Electro Polish | 15,10,7,5 | 0.38,0.25,0.20,0.13 | 32 | 0.8 |
SA213 TP 304L Tube Sizes
| Wall | Sizes (O.D.) |
|---|---|
| .010 | 1/16″, 1/8″, 3/16″ |
| .020 | 1/16″, 1/8″, 3/16″, 1/4″, 5/16″, 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″, 3/16″ |
| .028 | 1/8″, 3/16″, 1/4″, 5/16″, 3/8″, 1/2″, 3/4″, 1″, 1 1/2″, 2″ |
| .035 | 1/8″, 3/16″, 1/4″, 5/16″, 3/8″, 7/16″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 1 5/8″, 2″, 2 1/4″ |
| .049 | 3/16″, 1/4″, 5/16″, 3/8″, 1/2″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/8″, 1 1/4″, 1 1/2″, 1 5/8″, 2″, 2 1/4″ |
| .065 | 1/4″, 5/16″, 3/8″, 1/2″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 1 5/8″, 1 3/4″, 2″, 2 1/2″, 3″ |
| .083 | 1/4″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 1 5/8″, 1 7/8″, 2″, 2 1/2″, 3″ |
| .095 | 1/2″, 5/8″, 1″, 1 1/4″, 1 1/2″, 2″ |
| .109 | 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″ |
| .120 | 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 2″, 2 1/4″, 2 1/2″, 3″ |
| .125 | 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 2″, 2 1/4″ |
| .134 | 1″ |
| .250 | 2″ |
| .375 | 3 1/2″ |
